- Constant voltage/PWM output
- DALI & Push dimming function
- AC input: 200 - 240v AC
- Built-in active PFC function
- Efficiency up to 88.4%
- Over Temperature Protection: 100°C± 10°C
- Cooling by free air convection
- IP66 design for indoor and outdoor installation
- Suitable for intelligent LED lighting
Specifications
AC Current (Max.):
1.4A
Frequency Range:
47 - 63Hz
Full Load Efficiency (Typ.):
87% / 88.4%
Input Voltage:
- 200 - 240v AC
Inrush Current:
56A (Twidth=640μs 230v AC)
IP Rating:
- IP66
Leakage Current:
< 0.50mA
Load Regulation:
±2%
Output Current:
- 16.67A
- 8.34A
Output Voltage:
- 12v DC
- 24v DC
Power Factor:
PF>0.98/230v AC (Full Loading)
Rated Power:
- 200W
Size:
245 x 70 x 43mm
Voltage Tolerance:
±0.5%
Working Temperature:
-40°C to +60°C
UOM:
EA
